1.0 Quality Policy |
| Provide high quality products to meet the current and potential needs of customers. |
| 2.0 Quality Target |
| Never stop to continue improvement,Challenge Zero defects. |
| 3.0 Process Capability |
| Process Capability |
Mass Production |
Sample |
Process Capability |
Mass Production |
Sample |
| Max. layer number |
10 |
16 |
Max. work panel size |
546*622.5mm |
622*722mm |
| Press thicknessmm |
0.3¡ª5.0mm |
Max.work panel size for single side |
546*1200mm |
622*1500mm |
| Laminate tolerance |
+/-10% |
¡À8% |
Min.dielectric |
5mils |
4mils |
| Min.hole size |
8mils |
6mils |
COB line width min. |
3mils 3mils |
| Laser blind hole |
3¡ª10mils |
PTH tolerance for finished goods |
¡À3mils |
¡À2mils |
| Max.inner Cu( OZ ) |
6 |
6 |
Max. outlayer( OZ ) |
6 |
8 |
| Width/Spacing |
3.5/3mils |
3/2.5mils |
Min. solder mask bar |
3mils |
2.5mils |
| Counterbore hole |
¡À5mils |
¡À3mils |
Ni/Au thickess U¡± |
10¡ª80 |
| Aspect ratia |
5--10:1 |
18:1 |
Impedance control |
¡À10%(>50¦¸) |
| +/-5%>50¦¸£¨max£© |
| ¡À 10%(¡Ü50¦¸) |
| Back Drillingdepth tolerance |
¡À4mils |
¡À3mils |
POFV |
YES |
| HDI |
2+N+2 |
3+N+3 |
Outline tolerance |
¡À4mils |
¡À2mils |
| Single side |
22F,FR-1.FR-2.CEM-1.CEM-3.Al.Cu |
| FR-4 |
SY.GW.KB.EMC, IT,TUC,NY/NP. |
| High Frequence |
Zhongying.WL.Shenyi,Rogers,Taikoni. |
| High Speed |
EMC.TUC.ISOLA.M6.IT.SY | |
|
|
|
|
